CQ-BL21C33F
Specifications | ||
Camera | Image Sensor | 1/2.8” Progressive Scan CMOS |
Minimum Illumination | Color:0.001 Lux @ (F1.5,AGC ON); B/W:0.0005Lux @ (F1.5,AGC ON) | |
Shutter | 1/25s to 1/100,000s; Supports delayed shutter | |
Aperture | DC drive | |
Day/Night Switch | ICR cut filter | |
Digital zoom | 16x | |
Lens | Focal Length | 4.8-158mm, 33x Optical Zoom |
Aperture Range | F1.5-F4.0 | |
Horizontal Field of View | 58.9~2.4°（wide-tele） | |
Minimum Working Distance | 100mm-1500mm (wide-tele) | |
Zoom Speed | Approximately 3.5s (optical, wide-tele) | |
Compression Standard | Video Compression | H.265 / H.264 / MJPEG |
H.265 Type | Main Profile | |
H.264 Type | BaseLine Profile / Main Profile / High Profile | |
Video Bitrate | 32 Kbps~16Mbps | |
Audio Compression | G.711a / G.711u / G.722.1 / G.726 / MP2L2 / AAC / PCM | |
Audio Bitrate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-192Kbps(MP2L2) / 16-64Kbps(AAC) | |
Image（Maximum Resolution：1920*1080） | Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
Third Stream | 50Hz: 25fps (704x576); 60Hz: 30fps (704x576) | |
Image Settings | Saturation, Brightness, Contrast and Sharpness can be adjusted via the client-side or browser | |
BLC | Support | |
Exposure Mode | AE / Aperture Priority / Shutter Priority / Manual Exposure | |
Focus Mode | Auto Focus / One Focus / Manual Focus / Semi-Auto Focus | |
Area Exposure / Focus | Support | |
Defog | Support | |
Image Stabilization | Support | |
Day/Night Switch | Automatic, manual, timing, alarm trigger | |
3D Noise Reduction | Support | |
Picture Overlay Switch | Support BMP 24-bit image overlay, customized area | |
Region of Interest | Support three streams and four fixed areas | |
Network | Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, SMTP, SNMP, IPv6 |
Interface Protocol | ONVIF (PROFILE S,PROFILE G) | |
Smart Features | Smart Detection | Cross-border detection, area intrusion detection, entering / leaving area detection, hovering detection, personnel gathering detection, fast motion detection, Fire detection |
General | Working Temperature | -25℃~60℃, humidity≤95%(non-condensing) |
Materials | Front and rear covers, ADC12 aluminum alloy Upper and lower cover, 6061 aluminum alloy profile Sun visor, mineral reinforced PP Window glass, float glass (no coating) Sealing strip, silicone | |
Protection | IP66 | |
Power supply | DC12V | |
Power consumption | 2.5W MAX (ICR, 4.5W MAX) | |
Dimensions | 340*120*75mm | |
Weight | 3KG | |
Specifications | ||
Camera | Image Sensor | 1/2.8” Progressive Scan CMOS |
Minimum Illumination | Color:0.001 Lux @ (F1.5,AGC ON); B/W:0.0005Lux @ (F1.5,AGC ON) | |
Shutter | 1/25s to 1/100,000s; Supports delayed shutter | |
Aperture | DC drive | |
Day/Night Switch | ICR cut filter | |
Digital zoom | 16x | |
Lens | Focal Length | 4.8-158mm, 33x Optical Zoom |
Aperture Range | F1.5-F4.0 | |
Horizontal Field of View | 58.9~2.4°（wide-tele） | |
Minimum Working Distance | 100mm-1500mm (wide-tele) | |
Zoom Speed | Approximately 3.5s (optical, wide-tele) | |
Compression Standard | Video Compression | H.265 / H.264 / MJPEG |
H.265 Type | Main Profile | |
H.264 Type | BaseLine Profile / Main Profile / High Profile | |
Video Bitrate | 32 Kbps~16Mbps | |
Audio Compression | G.711a / G.711u / G.722.1 / G.726 / MP2L2 / AAC / PCM | |
Audio Bitrate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-192Kbps(MP2L2) / 16-64Kbps(AAC) | |
Image（Maximum Resolution：1920*1080） | Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
Third Stream | 50Hz: 25fps (704x576); 60Hz: 30fps (704x576) | |
Image Settings | Saturation, Brightness, Contrast and Sharpness can be adjusted via the client-side or browser | |
BLC | Support | |
Exposure Mode | AE / Aperture Priority / Shutter Priority / Manual Exposure | |
Focus Mode | Auto Focus / One Focus / Manual Focus / Semi-Auto Focus | |
Area Exposure / Focus | Support | |
Defog | Support | |
Image Stabilization | Support | |
Day/Night Switch | Automatic, manual, timing, alarm trigger | |
3D Noise Reduction | Support | |
Picture Overlay Switch | Support BMP 24-bit image overlay, customized area | |
Region of Interest | Support three streams and four fixed areas | |
Network | Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, SMTP, SNMP, IPv6 |
Interface Protocol | ONVIF (PROFILE S,PROFILE G) | |
Smart Features | Smart Detection | Cross-border detection, area intrusion detection, entering / leaving area detection, hovering detection, personnel gathering detection, fast motion detection, Fire detection |
General | Working Temperature | -25℃~60℃, humidity≤95%(non-condensing) |
Materials | Front and rear covers, ADC12 aluminum alloy Upper and lower cover, 6061 aluminum alloy profile Sun visor, mineral reinforced PP Window glass, float glass (no coating) Sealing strip, silicone | |
Protection | IP66 | |
Power supply | DC12V | |
Power consumption | 2.5W MAX (ICR, 4.5W MAX) | |
Dimensions | 340*120*75mm | |
Weight | 3KG | |
