CQ-JJ40-F
Feature:
| Model | CQ-JJ40-F |
| Operating Frequency Bands | 800MHz, 900MHz, 1.5GHz, 2.4GHz, 5.8GHz, 5.1GHz to 5.9GHz |
| Targeting Aircraft | Cooperative drones and some stealth aircraft |
| Interference Range | 0 ~ 2.5km (in open, unobstructed environments, the DJI Mavic2 drone has a 2.5km range) |
| Interference Response Time | ≤5s |
| Antenna Angle | Horizontal: 75° for frequencies below 2GHz, 30° for frequencies above 2GHz; Vertical: 65° for frequencies below 2GHz, 20° for frequencies above 2GHz |
| Interference Type | Analog source sweep interference |
| Location | Location is not supported by default. Need integrate a BDS positioning module to enable GNSS-based positioning. |
| Continuous Operation Time | 12 hours, maximum output power ≥30 minutes |
| Boot Time | 15 seconds |
| Communication Method | Customizable cellular mobile communication function |
| Power Supply | AC220V |
| Power Consumption | ≤400W |
| Mean Time Between Failures (MTBF) | 3000 hours |
| Mean Time To Repair (MTTR) | 1 hour |
| Operating Temperature | -20ºC to +60ºC |
| Storage Temperature | -25ºC to +65ºC |
| Protection Rating | IP43 |
| Dimensions | 260mm x 260mm x 150mm |
| Weight | ≤6.5kg (excluding power adapter) |
