384X288 12um CVBS Security Camera Analog Thermal Sensor

Availability:

Quantity:



Inquire Add to Basket

Model:
CQ-LTM4C12H

Product Description

Model	CQ-LTM4C12H
Infrared Module	Image Sensor	UFPA(VOx)
	Resolution	384x288
	Pixel Pitch	12μm
	Frame Rate	50Hz
	Spectral Range	8~14μm
	NETD	≤35mK
Image Processing	Bad Pixel Correction	Yes
	Non-uniformity Correction	Yes
	Digital Detail Enhancement	Yes
Functions	Digital Zoom	1~4x
	Image Calibration	Manual / Automatic (with shutter)
	Brightness / Contrast Adjustment	Manual / Automatic
	Polarity	White hot / Black hot
	Reticle	Display / Hide / Move
	Image Mirror	Left-right / Up-down / Diagonal
Power	Supply Voltage	DC12V (9V~15V)
	Power Dissipation	≤1.2W
	Reverse Connection Protection	Support
Interface	Video Output Interface	CVBS / MIPI
Interface	Communication Interface	RS422 / RS232
Environmental Parameter	Operating Temp.	-40ºC ~ +60ºC
Environmental Parameter	Storage Temp.	-45ºC ~ +70ºC
Physical Characteristics	Weight	≤38g
Physical Characteristics	Dimension	26mmx26mmx24mm
