CQ-LTML4C12-19H
| Model | CQ-LTML4C12-19H |
| Detector type | VOx Uncooled thermal Detector |
| Effective Pixels | 384x288 |
| Pixel size | 12μm |
| Response band | 8~14μm |
| NETD | ≤35mK(@F1.0, 300K) |
| Lens | 19mm athermalized lens |
| F value | F1.0 |
| FOV | 13.8° x 10.3° |
| Focusing range | 1M~∞ |
| Interface Protocol | ONVIF (Profile S, Profile G), SDK |
| Intelligent detection | Electronic fence, cross-border detection, area intrusion, leaving area |
| Resolution | 25fps (384x288) |
| Digital Zoom | 1x, 2x, 4x step 0.1 |
| Network Interface | 100M network port |
| Analog Output | CVBS |
| Communication serial port | RS232, RS485 |
| Power supply | DC12V±10% |
| Power consumption | 4W max |
| Operating temp. and humidity | -30ºC~60ºC, humidity less than 90% |
