CQ-LTML4C12-75MH
| Model | CQ-LTML4C12-75MH |
| Detector type | VOx Uncooled thermal Detector |
| Effective Pixels | 384x288 |
| Pixel size | 12μm |
| Response band | 8~14μm |
| NETD | ≤35mK(@F1.0, 300K) |
| Lens | 75mm manually focusing lens |
| FOV | 3.5° x 2.6° |
| Focus Range | 5m ~ ∞ |
| Interface Protocol | ONVIF (Profile S, Profile G), SDK |
| Resolution | 25fps (384x288) |
| Image settings | Brightness, contrast, and gamma are adjustable through the client or browser |
| Network Interface | 100M network port |
| Analog Output | CVBS |
| Communication serial port | RS232, RS485 |
| Storage function | Support Micro SD/SDHC/SDXC card (256G) offline local storage, NAS (NFS, SMB/CIFS are supported) |
| Power supply | DC12V±10% |
| Operating temp. and humidity | -30ºC~60ºC, humidity less than 90% |
