CQ-DM18x38-LS500
Specification | |
Model | CQ-DM18x38-LS500 |
Product name | 500M Laser Speed Dome Camera |
Laser | 500meter |
Imager | 1/2.8” Progressive Scan CMOS |
Effective Pixels | 1920×1080, 2 million pixels |
Minimum illumination | Color: 0.001 Lux @(F1.5, AGC ON); B/W: 0.0005 Lux @(F1.5, AGC ON) |
Automatic control | Auto white balance, auto gain, auto exposure |
Signal-to-noise ratio | ≥55dB |
BLC | switch |
Electronic shutter | 1/25～1/100,000 second, |
Day and night mode | Filter switch |
Digital zoom | 16 times |
Focus mode | automatic / manual |
focal length | 4.7mm～180mm, 38X |
Maximum aperture ratio | F1.5/F4.0 |
Horizontal perspective | 60.5 degrees (wide angle) ~ 2.3 degrees (distal) |
Minimum working distance | 100mm (wide angle), 1000mm (distal) |
Horizontal range | 360° continuous rotation |
Horizontal speed | 0.5°～150°/s, multiple manual control levels can be set |
Vertical range | -3°～+93° |
Vertical speed | 0.5°～100°/s |
Proportional zoom | support |
Number of preset points | 255 |
Cruise scan | 6 lines, 18 preset points can be added to each line, and the dwell time can be set |
Power-off self-locking | support |
Network Interface | RJ45 10Base-T/100Base-TX |
Maximum image size | 1920×1080 |
Frame rate | 25/30 fps |
Video compression | H.265 / H.264 / MJPEG |
Interface Protocol | ONVIF,GB/T 28181 |
Network protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, SMTP, SNMP, IPv6 |
Simultaneous visit | Up to 6 |
Dual stream | support |
Local storage | Micro SD card storage |
Safety | Password protection, multi-user access control |
Power supply | AC24V, 50Hz |
Power | 36W |
Protection level | IP66, 4000V lightning protection, anti-surge, anti-surge |
Operating temperature | -40℃～65 ℃ |
Working humidity | Humidity is less than 90% |
