CQ-CSH4C14HD
Model | CQ-CSH4C14HD | |
Camera | Image Sensor | 1/2.8” CMOS |
Day/Night Switch | ICR cut filter | |
Resolution | 4MP (2560x1440) | |
Field of View | Horizontal:55.8°~2.3°; Vertical:31.9°~1.3°; Diagonal: 63.7°~2.7° | |
Focal Length | 4.8mm～ 145mm (32x) | |
Scan | Progressive scanning | |
Synchronous | Internal synchronization | |
SNR | ≥50dB | |
BLC | Support | |
Day/Night Switch | Automatic / Manual | |
Minimum Illumination | Color: 0.05Lux @F1.4; B/W: 0.005Lux @F1.4 | |
White balance | Auto / Manual / Auto Tracking / Outdoor / Indoor / Sodium Lamp | |
Shutter | 1/1～30000 | |
Noise reduction | 2D/3D | |
Network | Video Compression | H.264 BaseLine / H.264Main Profile / H.264High Profile |
Protocols | IPv4/IPv6, HTTP,Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP,onvif | |
Multi-stream | Dual-stream, bit-stream interval | |
Safety | Password authentication, 3 levels of permission | |
Concurrent access | 6 Lines | |
PT | Rotation | Pan: 0～360°, tilt: -90°～+90° |
Speed | Pan: 0°~100°/S, Tilt: 0°~60°/S | |
Preset | 255 | |
Patrol tracks | Programmable (6 Lines) | |
Pattern scanning | Programmable (120s/Lines) | |
Speed limit | Automatically adjusts the manual control speed according to the size of the current zoom | |
Horizontal scanning | 360° programmable | |
Power-off memory | Support | |
Wiper control | Jogging / Continuous | |
IR | ≥120m | |
Ethernet | RS485 | |
Baud rate | 2400/4800/9600/19200 bps | |
Protocols | PELCO-D/P self-adaptive | |
Environmental | Fan/heater | Automatic (Built-in automatic thermostat) |
Defog | Heated with glass | |
Humidity | 10-90% | |
Storage Temp | -40℃～+60℃ | |
Power | AC24V±25% 50/60Hz（DC10V—DC30V for option) | |
Power consumption | 40W max | |
Ingress Protect | IP67 | |
Lightning sheath | GB/T17626.5 | |
Weight | 5.5Kg | |
